Allowable Motion Errors

2m/s

Resolution

≥4mil

Decode Capability

QR Code, Data Matrix, PDF417,Aztec, Maxicode,

UPC-A、UPC-E、EAN-13、EAN-8、Code 39、Interleaved 2 of 5、Industrial 2 of 5（Discrete 2 of 5）、Matrix 2 of 5、Code 128、UCC/EAN   128、Codabar、Code 93、Code 11、MSI、GS1 DataBar etc.

Decode Depth

（1 mil = 0.0254 mm）

EAN-13：60mm-160mm   (13mil)

Code39：50mm-80mm   (5mil )

QR Code：30mm-180mm   (20mil )

Data Marix：40mm-80mm   (10mil)

PDF 417：  40mm-90mm (6.67mil)

Input Voltage

DC 5V±0.2V

Operating Current

160 mA（Typical   value）/200 mA（Maximum   current）

Standby Current

<35mA

Indicator

Beep, LED

System interface

USB

Scan Mode

Manual Reading, Constant Light Reading, Inductive   Reading, Flashing Reading

Decode Angle

±50°，±65°，±35°（Skew, Pitch,   Roll）

Temperature

Work: -10°C to 60°C（-4°F to 140°F）；

Storage:    -40°C to 70°C（-40°F to 158°F）。

Humidity

5% to 90%

Anti-shock:

1.2meter

ESD Protection

Contact discharge: ±4KV，Air discharge：±8KV

Safety

CORH Class 2 laser product
